Your location > Home > Product > XL6013E1
For Your Information,References Product Description.

XLSEMI Primary Agent BOOST constant current drive IC XL6013E1

Model：
XL6013E1
Brand：
XLSEMI
Batch No：
XL6001,XL6003,XL6013E1,XLSEMI,上海芯龍
Desc：
400KHz 60V 2A Switching Current Boost LED Constant Current Driver
Stock：
0 只
PDF：
下載數據手冊 Download PDF
Enquiry Quantity：
Topological : 開關式升壓LED恒流驅動（內置MOS）
Package : SOP8L
Max. power output : 0~8W
LED serial number : 3~18串
Input voltage : 5V~40V
Output voltage : 8V~60V
Max. Input Current : 2A
Efficiency : 93%
Mosfet : 內置2A開關MOS
Switching frequency : 固定400KHz開關頻率
Dimming mode : FB腳串接1N4148進行PWM Dimming
Current accuracy : ±5%
Replacement models : XL6001E1,XL6003E1
Typical applications : MR16射燈，LED臺燈，LED車燈，LED燈條
